Name: XZW wandmontierte 2-Achsen-Kombination
Brand: Jem Dar Precision Co., Ltd.
SKU: Baureihe XZW
Availability: InStock

XZW wandmontierte 2-Achsen-Kombination Baureihe XZW

Prev Nächste ANFRAGE

Product Introduction

Der Hub der XZ-Achse beginnt bei 100 mm, und das Intervall beträgt 100 mm. der maximalen Hub und Last (S=Hub)							XZsuggested motor spec of XY-axis	附記
X-JDB-240-(S100~S2500mm) Z-JDB-180-Hub-/Lastgrenze	" Hub der Z-Achse: "	100mm	200mm	300mm	400mm	500mm	X-750W	壁掛式Z軸不易過長使用
X-JDB-240-(S100~S2500mm) Z-JDB-180-Hub-/Lastgrenze	" Endlast: "	65KG	57KG	49KG	41KG	33KG	Z-750W+Brake
X-JDB-180-(S100~S2200mm) Z-JDB-130- Hub-/Lastgrenze	" Hub der Z-Achse: "	100mm	200mm	300mm	400mm	500mm	X-400W
X-JDB-180-(S100~S2200mm) Z-JDB-130- Hub-/Lastgrenze	" Endlast: "	35KG	31KG	29KG	25KG	22KG	Z-400W+Brake
X-JDB-130-(S100~S1200mm) Z-JDBN-80- Hub-/Lastgrenze	" Hub der Z-Achse: "	100mm	200mm	300mm	400mm	-	X-200W
X-JDB-130-(S100~S1200mm) Z-JDBN-80- Hub-/Lastgrenze	" Endlast: "	17KG	16KG	14KG	13KG	-	Z-200W+Brake
X-JDBN-80-(S100~S800mm) Z-JDBN-65-Hub-/Lastgrenze	" Hub der Z-Achse: "	100mm	200mm	300mm	400mm	-	X-100W
X-JDBN-80-(S100~S800mm) Z-JDBN-65-Hub-/Lastgrenze	" Endlast: "	8KG	5KG	3KG	1.5KG		Z-100W+Brake
