Product Introduction
| Motor capacity | Stepping motor / servo motor: 1.3Nm | ||
|---|---|---|---|
| Pitch (mm) | 2 | 5 | 10 |
| Dynamic load | 12.7 kg | ||
| Static load | 17.6 kg | ||
| Line speed (mm/sec) | 50 | 250 | 500 |
| Horizontal load (kg) | 12 | 9 | 8 |
| Vertical load (kg) | 8 | 7 | 4 |
| Acceleration (m/sec2) | 0.5 | 1.25 | 2.5 |
| Vertical drive torque (Nm) | 0.03 | 0.068 | 0.087 |
| Rated torque (N) | 678.6 | 271.4 | 135.7 |
| Repeatability (mm) | C: ±0.01 mm P:±0.005 mm UP:±0.001 mm | ||
| Effective stroke (mm) | 20 mm~100 mm (interval 20mm) | ||
| Ambient temperature / humidity | 0~40°C/ 30~85% RH | ||
| Limited switch | DC 5V~24V/ DU-911 x 2 sets/ wire length 30 cm | ||
